Cabstrut Brackets (or Fittings), unless otherwise noted, are manufactured from hot-rolled, pickled and oiled steel plates, strip or coils complying with BS 1449-1.2:1991 or BS4360:1990 having a minimum yield stress of 170N/mm¬? as specified in BS6946:1988.

Cabstrut Brackets (or Fittings), unless otherwise noted, are hot-dip galvanised after manufacture to SANS 121:2001 / ISO 1461:2009

Standard Dimensions: The following dimensions apply to all Cabstrut Brackets (or Fittings), except where noted on the part drawing:
- Hole size: 14mm diameter
- Hole spacing: 20,5mm from end of fitting and 48mm centre to centre.
- Fitting width: 40mm unless otherwise noted.
- Fitting thickness: 6mm unless otherwise noted.
All dimensions are subject to commercial tolerances.

Cabstrut Brackets (or Fittings) only show one application of each item. More than one application is possible in most cases.
